Polygim Mini-88-25
| Double Spindle 25 Type (Main Spindle) | Double Spindle 25 Type (Sub Spindle) | |
|---|---|---|
| Max. Machining Dia. | Ø80 mm | Ø80 mm |
| Max. Machining Length | 220 mm | 220 mm |
| Swing | Ø400 mm | Ø400 mm |
| X Axis | 80 mm | 80 mm |
| Z Axis | 280 mm | 220 mm |
| Rapid Traverse | 12 m/min | 12 m/min |
| Bar Capacity | Ø26 mm | Ø26 mm |
| Bore of Spindle | Ø26 mm | Ø26 mm |
| Spindle Nose | Ø85 mm | Ø85 mm |
| Chuck | 4" | 4" |
| Collet Type | 161E | 161E |
| Spindle Motor | 2.2 kw | 1.5 kw |
| X, Z, A Axis Motor | 0.75 kw | 0.75 kw |
| Spindle Speed | 100~6000 r.p.m. | 100~6000 r.p.m. |
| O.D. Tool | □16 mm | □16 mm |
| I.D. Tool | Ø20 mm | Ø20 mm |
| Coolant Pump | 1 H.P. | 1 H.P. |
| Dimension | 2000 x 1200 x 1680 mm | 2000 x 1200 x 1680 mm |
| Weight | 1490 kg | 1490 kg |
