| Swing over bed |
Φ1100 mm |
| Swing over cross slide |
Φ800 mm |
| Max. Workpiece length |
1500 / 3000 / 4000 / 5000 mm |
| Width of bed |
600mm |
| Chuck size |
φ320 mm |
| Spindle steps |
3 steps, stepless in each step |
| Spindle speed range |
14-1000 rpm |
| Spindle bore dia. |
104/130 mm |
| Spindle taper |
Metric 120 / Metric 140 |
| Spindle nose |
A2-11 |
| Tool post travel |
200 mm |
| X-axis travel |
470 mm |
| Z-axis travel |
1350 / 2850 / 3850 / 4850 mm |
| Tool post Type |
Manual |
| Tool station No. |
4 |
| Tool size |
32X32 mm |
| Travel type |
Manually |
| Quill stroke |
250 mm |
| Quill dia. |
φ100 mm |
| Quill taper |
MT5 |
| No. of longitudinal and cross feed |
38 |
| Longitudinal feed range(Metric) |
0.05-6.4 mm/rev |
| Cross feed range(Metric) |
0.025-3.2 mm/rev |
| Longitudinal feed range(Inch) |
0.002-0.242 inch/rev |
| Cross feed range(Inch) |
0.001-0.121 inch/rev |
| X/Y axis rapid speed |
2/6 M/min |
| Thread Pitch Metric(31 kinds) |
0.5-40 mm |
| Thread Pitch Inch(54 kinds) |
1-80 T.P.I |
| Modules(26 kinds) |
0.25-20 M.P |
| Diametral(31 kinds) |
2-72 D.P |
| X/Z aixs ball screw Dia. |
Φ25×5 / φ63×12(E115) Φ25×5 / φ63×20 mm |
| Main servo motor power |
15/18 kW |
| Coolant motor power |
0.2 kW |
| X/Z axis servo motor power |
2.3 / 2.3 kW |
| Spindle torque |
3280 N.m |
| X/Z motors allowable torque |
15/15 N.m |
| Overall dimension |
3650×1800×1850 mm, 5650×1800×1850 mm, 6650×1800×1850 mm, 7650×1800×1850 mm |
| Approximate net weight |
5600 / 6200 / 7100 / 7700 kg |
