| Max. Machining Dia. |
25 mm |
| Max. Machining Length |
Bar diameter x 3 |
| X Axis |
165 mm |
| Z Axis |
150 mm |
| Y Axis |
148 mm |
| Bore of Spindle |
34 mm |
| Bar Capacity |
26 mm |
| Spindle Nose |
Ø85 mm |
| Collet Type |
161 E / 25 mm |
| Spindle Motor |
2.2 kw / 3 H.P. |
| X, Z, Y Axis Motor |
0.75 kw |
| Cross and Front off-Center Driven Tools Motor |
0.75 kw |
| Spindle Speed |
100-6000 r.p.m. |
| Cross Spindle Speed |
200-6000 r.p.m. |
| Front off-Center Driven Tool Speed |
200-6000 r.p.m. |
| Spindle Indexing |
5° |
| Rapid Traverse Speed (X, Z, Y Axis) |
12 m/min |
| Min. Input Unit |
0.001 mm |
| O.D. Tooling |
6 |
| O.D. Tool Dimension |
□12 X 12 X 100 |
| I.D. Tooling |
4 |
| I.D. Tool Dimension |
Ø20 mm |
| I.D. Tool Max. Drilling Dia. |
Ø20 mm |
| I.D. Tool Max. Tapping Dia. |
M8 |
| Cross Driven Tooling |
4 |
| Cross Driven Tooling Dimension |
10 mm (ER16) |
| Cross Driven Tool Max. Drilling Dia. |
Ø10 mm |
| Cross Driven Tool Max. Tapping Dia. |
M8 |
| Front off-Center Driven Tooling |
4 |
| Front off-Center Driven Tool Dimension |
10 mm (ER16) |
| Front off-Center Driven Tool Max. Drilling Dia. |
Ø10 mm |
| Front off-Center Driven Tool Max. Tapping Dia. |
M8 |
| Coolant Pump |
1/2 H.P. |
| Hydraulic Pump |
1/2 H.P. |
| Dimension |
1420 x 1210 x 1710 mm |
| Weight |
1288 kgs |
