| Max. Machining Dia. |
60 with chuck, 26 with collet chuck |
| Max. Machining Length |
Bar diameter x 3 |
| Swing Over Cross Slide |
160 mm |
| Max. Cross Travel (X axis) |
230 mm |
| Max.Longitudinal Travel (Z axis) |
230 mm |
| Bore of Spindle |
38 mm |
| Max. Bar Feeding Dia. |
26 mm |
| Spindle Nose |
Ø85 mm |
| Hydraulic Chuck |
4" |
| Spindle Motor |
3.7 kw / 5 H.P. |
| Spindle Speed Range |
100-6000 r.p.m. |
| Rapid Traverse Speed (X, Z Axis) |
16 m/min |
| Min. Input Unit |
0.001 mm |
| Cutting Tool Size |
□20 mm |
| Max. Bore Size of Tool |
Ø25 mm |
| Coolant Pump Motor |
1/4 H.P. |
| Machine Dimension (Chip Conveyor) LxWxH |
2440 x 1490 x 1830 mm |
| Machine Dimension (LxWxH) |
1830 x 1490 x 1830 mm |
| Machine Net Weight |
1680 kgs |
